Recursion
Recursion OverviewMaze Program
for this lab you will complete the maze algorithm add the code in described in the comments
File: main1.cpp
#include "easylogging++.h"
INITIALIZE_EASYLOGGINGPP
#include <iostream>
#include <stdlib.h>
#include <string.h>
#include "cmpslib19.h"
using namespace std;
int speed = 100;
#define ROWS 50
#define COLUMNS 122
#define StartingX 1
#define StartingY 1
char MAZE[][COLUMNS] =
{
"+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+",
"| | | | | | | | | | | | | | | | | | | | | | |",
"+-+-+-+ + +-+ + +-+ + + + + +-+-+ + + + + +-+ + + +-+ + +-+-+-+ + + +-+ + + +-+ + + +-+ + + +-+-+ + + +-+ + + + + + + + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+-+-+ +-+-+-+-+-+-+-+ +-+ + + + +-+-+ + +-+-+-+ + + +-+ + + +-+-+-+-+ +-+ +-+ + + +-+-+ + +-+ + + + +-+-+-+ + +-+-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + + +-+ + +-+ +-+ + + +-+ + +-+ + + +-+-+-+ +-+-+ +-+-+-+ +-+ + +-+ +-+ +-+ + + +-+-+ +-+ +-+-+ + + +-+-+-+-+-+ + +-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + +-+ + + + +-+ +-+ +-+ + +-+-+-+ + + + +-+-+ + +-+-+-+-+-+ +-+-+-+ + +-+ +-+-+ +-+-+-+ +-+-+ +-+-+ + +-+-+-+ +-+ + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + + +-+ + + + +-+-+-+ +-+-+ +-+ +-+-+ + + +-+ + +-+-+-+-+ + + + +-+ +-+-+ +-+ +-+ +-+ + + +-+-+ + +-+-+ +-+-+ + +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + +-+-+-+ + +-+ + + +-+-+ + + + +-+ + +-+-+ + +-+-+ + + + + +-+-+ +-+ +-+ + +-+-+-+ +-+-+ + +-+-+-+ + + +-+ +-+-+-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+-+-+-+ + + +-+-+ + + +-+-+-+-+ + +-+-+-+-+ + +-+-+-+ + +-+ + +-+-+-+-+ + + +-+-+ + + +-+ +-+ + + +-+ +-+-+ + +-+ + + +-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + +-+-+-+ + + + +-+-+-+ + + + + + +-+ +-+-+-+ +-+ +-+ +-+-+ + +-+ + +-+-+-+ + +-+-+ +-+ + + +-+-+-+ +-+-+-+-+-+ +-+-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+-+ + + +-+ + + + + + + +-+-+ +-+ + +-+ + + +-+ + + +-+ + + +-+ + +-+ + + + +-+ + +-+-+-+-+-+-+ + +-+ + +-+-+ +-+-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + + +-+-+ + + + +-+ +-+-+ +-+-+ + +-+ + +-+-+ +-+-+ + +-+ + + + +-+ +-+-+ + + + + + +-+-+-+ + + +-+ + + + + +-+ +-+-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+ +-+-+-+-+-+-+-+-+-+-+ + + + +-+ + +-+-+ + + + +-+-+-+-+-+ + + + +-+ +-+-+ +-+ +-+ + + +-+ +-+-+ +-+ + +-+-+-+-+ + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+-+ +-+ + +-+-+-+ +-+ +-+ +-+ + +-+-+-+ + + + + + +-+ + +-+ + + +-+ +-+ +-+ + +-+ +-+ +-+-+-+ +-+ + + + + +-+ + + + + + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+ + + + +-+-+-+ + + +-+ +-+ + +-+ + +-+-+ + + + +-+ +-+-+-+ + +-+ + + + + + +-+-+-+ + +-+-+-+-+ +-+ + +-+ + +-+ +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + +-+ +-+-+ +-+-+-+-+ +-+-+ +-+ + +-+ +-+-+-+-+-+-+-+-+ +-+ + +-+-+-+ +-+ + + + + + +-+ + +-+-+-+ + + + + +-+ + +-+ +-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + +-+ + + + + +-+ + + + +-+-+-+-+ + + +-+-+-+ + +-+ + + +-+-+ + + +-+ + +-+ + + + + + +-+ +-+-+-+ +-+-+-+ + + + + + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + +-+-+-+ + + +-+-+-+-+-+-+-+ + + +-+-+ + +-+-+-+-+-+-+ +-+ + +-+-+-+ + +-+-+-+ +-+-+-+-+-+-+ + +-+ + +-+-+-+-+-+ +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + + + +-+ + + +-+ + +-+ +-+-+ +-+-+-+-+-+ +-+-+ + +-+ +-+-+-+ + + + + + +-+ +-+-+-+-+-+-+ + + + + + +-+-+ + + + +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+-+-+-+ + + + + + +-+ + +-+ +-+-+-+-+ + +-+ +-+-+-+ +-+-+ + +-+ + +-+-+-+-+ + +-+ +-+-+-+-+ +-+-+ + + + + +-+ + + +-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + +-+-+ + + + +-+-+ + +-+-+-+ + + +-+ + +-+-+-+-+ + + +-+-+-+ +-+-+ +-+ + + +-+ + +-+-+ + + +-+ + +-+-+-+ + + + + +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+ + +-+ + +-+ +-+ +-+-+ + +-+-+ + + + + + +-+-+-+ +-+ + +-+-+ + +-+ + + +-+-+-+ +-+ + + + + +-+ + + + +-+ +-+-+-+ +-+",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + +-+-+ +-+-+-+-+-+ +-+-+-+ + +-+-+-+ +-+-+-+ +-+ +-+-+ +-+-+ + +-+-+ + +-+ +-+-+-+-+-+ + + +-+ +-+-+ + + +-+ +-+ +-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ +-+ + +-+ +-+ + +-+-+-+-+-+-+-+ +-+ +-+ + + + +-+ + +-+-+ +-+-+ + + +-+ + + + +-+-+ +-+ + +-+-+-+ + +-+ + +-+ +-+-+ + +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+-+-+ +-+-+-+ + +-+-+ +-+ +-+ + +-+ +-+ +-+-+-+-+ + + + +-+-+ + +-+-+ +-+-+ +-+-+ + + + +-+ +-+ +-+-+-+-+-+-+-+ + +-+-+ +",
"| | | | | | | | | | | | | | | | | | | | | | | | | | | |",
"+ + + + +-+-+-+-+-+ +-+-+ + + +-+-+ + + + +-+-+-+-+ + +-+ + +-+-+ + + +-+-+-+-+ + + + +-+-+-+ + + + +-+ + + +-+-+-+ + +-+",
"| | | | | | | | | | | | | | | | | | | F",
"+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+"
};
//--------------------------------------------------------------------
void printMaze()
{
// we want to redraw the maze so move the cursor back so we print in the same place
PositionCursor(0,0);
cout << ChangeToGreen() ;
for(int rows=0;rows <= ROWS ;rows++)
{
for (int columns=0;columns < COLUMNS;columns++)
{
PositionCursor(rows,columns);
cout << MAZE[rows][columns];
}
cout <<"\n";
}
}
//---------------------------------------------------------------------
bool Step(int x, int y, int level)
{
// we need a terminating condititon so we dont keep calling the function forever
// we stop when we find the end of the maze
// is the point x, y the finish? 'F' (MAZE[x][y]=='F')
// if so cout "Finish Found at.... "
// and return true
// if the point x,y is not an empty space ' ' return false
// we can only proceed if it is and empty space
// so now we know that point x,y is a space
// set MAZE[x][y] to the char '@'
// draw the @ in the maze at the appropriate position
// set the cursor postition to x,y , use function PositionCursor
// print the char '@'
// print some debugging info, mine prints current location
// and how many levels deep we are */
PositionCursor(ROWS +1,0);
cout << ChangeToGreen()<< "currently at "<<x<<","<<y<< " " << endl;
cout << level << " levels deep\n";
// pause for a while
WaitHundredth(speed);
// call Step and pass in the coordinates of one space to the right ( x+1,y )
// if it returns true you found the end and return true as well
// call Step and pass in the coordinates of one space to the left ( x-1,y )
// if it returns true you found the end and return true as well
// call Step and pass in the coordinates of one space down ( x,y+1 )
// if it returns true you found the end and return true as well
// call Step and pass in the coordinates of one space up ( x,y-1 )
// if it returns true you found the end and return true as well
// if we are here we have not found the end...
// we tried going up , down , left and right and didnt find the end
// we must be at a dead end so we want erase that we came this way
// and return false
// first set this position in the array to ' ' to delete the '@'
// and draw a space back to erase our path on the map as we go back and try another direction
// set the cursor position to x and y
// and print a space at this position
// return false
return false;
}
//-----------------------------------------------------------------
int main()
{
Prompt("What delay do you want between moves... 1-99:",speed,1,99);
system("clear");
printMaze();
Step(StartingX ,StartingY,1);
return 0;
}
